VFW-614 Prototype - T-Tail Warrior Packs

Configuration Validation and Early Design Concept. The prototype VFW-614 aircraft were drawn to validate the feasibility of the over-wing engine configuration and short-field performance goals.

Key Characteristics:

Early fuselage configuration with development instrumentation.
Initial wing geometry prior to later refinements.
Prototype-specific T-tail and pylon shaping proposal.
Structural accommodations for test equipment.
Flight-test oriented systems layout proposal.

CAD Notes

The prototype model preserves early-stage geometry, highlighting differences from later production aircraft.
These include T-tail transitions, nacelle integration details, and fuselage proportions that were refined during certification.

This variant is particularly useful for studying configuration risk mitigation and early aerodynamic decision-making.

CAD Reconstruction Approach

All models in this project are created as engineering-grade CAD geometry, not visualization meshes. Fully lofted NURBS surfaces:

Solid-body fuselage, wing, and nacelle geometry
Parametric structure allowing dimensional analysis
Cross-sections exportable for DXF / DWG
Variant-specific geometry changes preserved

The goal is geometric and aerodynamic fidelity, suitable for study, comparison, and fabrication workflows.

Why the VFW-614 Matters

Despite limited production, the VFW-614 occupies an important place in aerospace history:

Demonstrated alternative engine placement strategies
Influenced thinking on regional jet operations
Served as a critical fly-by-wire research platform
Bridged civil transport and experimental research domains

Preserving the aircraft in CAD form allows these contributions to be studied beyond photographs and general descriptions.

Repository Intent

This project is intended for:

Aerospace engineers and students
Flight-control and aerodynamics researchers
CAD and geometry enthusiasts
Modelers and fabricators
Aviation historians

Pack A — 3D Printing Pack (STL + 3MF Only)

Get ze VFW-614 T-Tail 3D Printing Pack for €10 Here

Includes:

High-resolution STL of the aircraft
Included Custom Aircraft Stands
Clean watertight mesh suitable for resin or FDM printing
3MF file for layout reference
Aerodynamic, smooth loft surfaces just like wind tunnel models
Ready for slicing (Cura, PrusaSlicer, Bambu Studio, Orca-Slicer)
Optional: scaled versions (1:150, but can be re-sized as 1:72, 1:144, 1:48, etc.)

Perfect for: Collectors · Modelers · 3D printer hobbyists
